Applications:
Suction of aggressive chemical fumes and gases in all fields of industry
Properties:
Good temperature and chemical resistance, outer wear strip, good compressibility
Temperature Resistance:
– 150°C to + 250°C
Material:
PTFE coated glass fabric
Colour:
Brown
Single Length:
3m and 6m lengths; custom lengths can be requested
Special Construction:
Teflon EL CL – Conductive (R<106 Ohm), conform to TRBS 2153
Technical Data
| Dia. (mm) |
Weight (kg/m) |
Mat. Thickness (mm) |
Bend. Rad. (mm) |
Max. Work. Press. (bar) |
Max. Vacuum (bar) |
| 50 | 0.40 | 0.12 | 30 | 0.85 | 0.32 |
| 60 | 0.50 | 0.12 | 36 | 0.68 | 0.22 |
| 76 | 0.60 | 0.12 | 45 | 0.47 | 0.14 |
| 80 | 0.63 | 0.12 | 48 | 0.43 | 0.12 |
| 102 | 0.65 | 0.12 | 60 | 0.30 | 0.08 |
| 110 | 0.70 | 0.12 | 66 | 0.25 | 0.07 |
| 120 | 0.72 | 0.12 | 72 | 0.22 | 0.06 |
| 127 | 0.80 | 0.12 | 75 | 0.21 | 0.05 |
| 152 | 0.90 | 0.12 | 90 | 0.16 | 0.04 |
| 160 | 0.94 | 0.12 | 96 | 0.14 | 0.03 |
| 180 | 1.05 | 0.12 | 108 | 0.12 | 0.02 |
| 203 | 1.21 | 0.12 | 120 | 0.10 | 0.02 |
| 254 | 1.70 | 0.12 | 175 | 0.07 | 0.01 |
| 305 | 2.13 | 0.12 | 210 | 0.05 | 0.01 |
| 350 | 2.30 | 0.12 | 245 | 0.04 | 0.01 |
| 407 | 2.90 | 0.12 | 280 | 0.03 | 0.01 |
| 508 | 3.90 | 0.12 | 400 | 0.02 | 0.01 |
